Integral LED
150W 0.6M VECTOR MAX LINEAR HIGH BAY IP44 IK10 27000LM 180LM/W 4000K 30x70° BEAM ZHAGA 18 PLUG-N-PLAY - ILHBL303
150W 0.6M VECTOR MAX LINEAR HIGH BAY IP44 IK10 27000LM 180LM/W 4000K 30x70° BEAM ZHAGA 18 PLUG-N-PLAY - ILHBL303
Couldn't load pickup availability
The Integral LED Vector Max Linear High Bay is built to last in the most demanding industrial environments. Compact, powerful and efficient, the Vector Max offers a high lumen output for its size at an incredibly efficient 180lm/W. IP44 ingress protection rated and IK10 shock-resistance makethis rugged luminaire ideal for warehouses, production facilities, factories and other industrial environments.The 30x70° asymmetrical beam angle makes this light perfect for long and narrow spaces like in between warehouse racking.The Vector Max features a Zhaga 18 socket for plug and play control and sensor add ons, including Casambi, PIR and microwave. Surface mounting brackets sold separately. See related products for accessory options.
- Product Feature 1:
- 27000lm
- Product Feature 2:
- Zhaga 18 plug n play
- Product Feature 3:
- 4000K
- Product Feature 4:
- 180lm/W
- Product Feature 5:
- Class I
- Product Feature 6:
- 5 Year Warranty
- Product Feature 7:
- IP44
- Product Feature 8:
- IK10
Share
Details
Details
- Barcode: 5055788284765
- Category: Luminaires
- Range Name: Vector Max
- Type: Linear
- Product Type: Linear High Bay
- Product Body Finish: Silver
- Market Segment: Commercial indoor, Industrial indoor
- Finish: Silver
- Features: 180lm/W
- Warranty (Years): 5
Physical Data
Physical Data
- Emergency Option: No
- Size (in ft): 2ft
- Product Length (mm): 612
- Product Depth (mm): 96
- Product Width (mm): 112
- Product Weight (g): 3200
- Optic: Polycarbonate diffuser
- Material: Aluminium
- Construction: Aluminium
- Bulb or Luminaire Shape: Linear
- Luminaire Fixing: Suspended / ceiling mounted / wall mounted
- Placement / Application: Indoor, General Lighting
- Typical Mounting Height: 5M
Light Data
Light Data
- Luminous Flux in Lumens (lm): 27000
- Luminous efficacy (lm/W): 180
- Correlated Colour Temperature (CCT) (K): 4000
- Colour Temperature Name: Cool White
- Beam Angle: 30x70
- Colour Rendering Index (CRI): 80
- Frequency Range (Hz): 47/63 Hz
- Instant on (Less than 1 second): Yes
- LED Size (mm): 2835
- LED Type: Surface mounted device (SMD)
- Lifetime (hours): 50000
- Switching Cycles: 100000
Electrical Data
Electrical Data
- Power Factor: 0.95
- Voltage Range (v): 200-240
- Input Voltage (V): 200-240
- Dimming: Dimmable
- Driver Included: Yes
- Electric Current: AC
- Protection Function: Short Circuit, overload and overheating protection on driver
- EN: EN-60598
- LVD Certified: Yes
Environmental
Environmental
- EN: EN-60598
- LVD Certified: Yes
- CE RoHS: Yes
- EU Luminaire: L
- Hg 0% (Mercury Free): Yes
- IK Rating (Impact Protection): IK10
- IP Rating (Ingress Protection): IP44
- Lowest Operating Temperature (°C): -35
- Maximum Operating Temperature (°C): 50
