CONSTANT VOLTAGE DRIVER 15W 24VDC IP20 NON-DIMM 200-240V INPUT INTEGRAL - ILDRCVA086

CONSTANT VOLTAGE DRIVER 15W 24VDC IP20 NON-DIMM 200-240V INPUT INTEGRAL - ILDRCVA086

£5.77 exc. VAT
exc. VAT
exc. VAT
 £5.77

£6.92 inc. VAT
Sale Sold out
Shipping calculated at checkout.

The Integral 15W constant voltage LED driver operates 200-240VAC input range. The LED driver provides 24V constant voltage and up to 0.625A of output current for a 15W maximum output power. Integral LED drivers deliver high reliability and efficiency >= 84% and are fully compatible with 24V constant voltage LED lighting systems. The LED driver features an ultra slim, IP20 rated casing that helps to provide an easy installation and smart finish, ideal for indoor use.

Product Feature 1:
Input Voltage: 200-240VAC
Product Feature 2:
Output Power: 15W
Product Feature 3:
Output: 24VDC Constant Voltage
Product Feature 4:
Short Circuit / Over Load / Over Heat Protection
  • Quick Order Code: 821852
  • Barcode: 5055788256694
  • Category: Drivers
  • Range Name: Non-Dimmable
  • Product Type: Constant Voltage
  • Market Segment: Commercial indoor, Residential indoor
  • Warranty (Years): 3
  • Product Length (mm): 103
  • Product Width (mm): 35.5
  • Product Weight (g): 16
  • Material: Plastic Shell
  • Placement / Application: Indoor
  • Frequency Range (Hz): 50/60
  • Power Consumption (W): 15
  • Power Factor: ≥0.5
  • Voltage (V): 24
  • Input Current (A): <0.23
  • Input Voltage (V): 200-240VAC
  • Output Current (mA): 0-0.625
  • Dimming: Non-Dimmable
  • Protection Function: Short Circuit Protection, Overload Protection, Overheat Protection
  • EN: EN61347-1, EN61347-2-13, EN55015, EN6100-3-3, EN6100-3-2, EN61547
  • LVD Certified: Yes
  • EN: EN61347-1, EN61347-2-13, EN55015, EN6100-3-3, EN6100-3-2, EN61547
  • LVD Certified: Yes
  • CE RoHS: Yes
  • Hg 0% (Mercury Free): Yes
  • IP Rating (Ingress Protection): IP20
  • Lowest Operating Temperature (°C): -20
  • Maximum Operating Temperature (°C): 45
