Integral LED

CONSTANT VOLTAGE DRIVER 480W 48VDC IP65 NON-DIMM 90-305V INPUT - HLG-480H-48A

CONSTANT VOLTAGE DRIVER 480W 48VDC IP65 NON-DIMM 90-305V INPUT - HLG-480H-48A

£248.48 exc. VAT
exc. VAT
exc. VAT
 £248.48

£298.18 inc. VAT
Sale Sold out
Shipping calculated at checkout.

This non-dimmable 480W constant voltage LED driver operates 90-305VAC input range. The LED driver provides 48V constant voltage for applications such as 48V LED strip lighting.

Product Feature 1:
Input Voltage: 90-305VAC
Product Feature 2:
Output Power: 480W
Product Feature 3:
Output: 48VDC Constant Voltage
Product Feature 4:
Short Circuit / Over Load / Over Heat Protection
  • Quick Order Code: 308420
  • Barcode: 5055788257868
  • Category: Drivers
  • Range Name: Non-Dimmable
  • Product Type: Constant Voltage
  • Market Segment: Commercial indoor
  • Warranty (Years): 5
  • Product Length (mm): 262
  • Product Depth (mm): 43.8
  • Product Width (mm): 125
  • Product Weight (g): 2470
  • Placement / Application: Indoor LED Lighting
  • Frequency Range (Hz): 50/60
  • Power Consumption (W): 480
  • Power Factor: 0.97
  • Voltage (V): 48
  • Voltage Range (v): 90-305
  • Input Current (A): 2.45
  • Input Voltage (V): 90-305VAC
  • Output Current (mA): 10000
  • Dimming: Non-Dimmable
  • Protection Function: Short Circuit Protection, Overload Protection, Overheat Protection
  • EN: EN61347-1, EN61347-2-13, EN55015, EN6100-3-3, EN6100-3-2, EN61547
  • LVD Certified: Yes
  • EN: EN61347-1, EN61347-2-13, EN55015, EN6100-3-3, EN6100-3-2, EN61547
  • LVD Certified: Yes
  • CE RoHS: Yes
  • Hg 0% (Mercury Free): Yes
  • IP Rating (Ingress Protection): 65
  • Lowest Operating Temperature (°C): -40
  • Maximum Operating Temperature (°C): 50
