EVOFIRE FIRE RATED DOWNLIGHT 70MM CUTOUT IP65 ANTIQUE BRASS ROUND +GU10 HOLDER & INSULATION GUARD INTEGRAL - ILDLFR70D046
EVOFIRE FIRE RATED DOWNLIGHT 70MM CUTOUT IP65 ANTIQUE BRASS ROUND +GU10 HOLDER & INSULATION GUARD INTEGRAL - ILDLFR70D046
Couldn't load pickup availability
The Evofire Fire Rated Downlight is a safe and attractive fitting for a GU10 or MR16 LED lamp. The fully open design of the Evofire does not conceal your lamp in a large metal canister, which can trap some of the heat it generates, lowering lamp lifetime and performance. Lamps installed in an Evofire run at up to 10 degrees C cooler than a typical can-style fire rated downlight from leading LED brands - this can extend the lifetime of your lamps.As well being very tough thanks to its steel construction, The Evofire is also a highly aesthetic choice for Fire Rated lighting. The 1mm blend-in bezel is up to 10 times thinner than typical IP65 rated downlights, has a high quality powder coating and fits almost flush with your ceiling, so the downlight looks discreet and pleasing in any setting.Featuring a built-in Insulation Guard which allows loft insulation to be safely laid on top of the downlight, while maintaining air-flow around the lamp.This downlight is fire rated to 30, 60 and 90 minutes in compliance with BS476 Part 21:1987, Air Tightness compliant with Part C and Part L and Resistance to Sound compliant with Part E. See installation guide for full details.Evofire shown with Real Colour GU10 LED lamp (sold separately).
- Product Feature 1:
- Evolutionary Fire Rated fitting designed by Integral LED
- Product Feature 2:
- Developed in the UK - Patent GB2557957
- Product Feature 3:
- Fire Rating 30/60/90 minutes - Tested in UKAS Accredited Lab
- Product Feature 4:
- Ultra-thin 1mm 'blend-in' bezel
- Product Feature 5:
- Easy to install Loop-in/Loop-out piano-key style terminal block
- Product Feature 6:
- Supplied with GU10 holder
Share
Details
Details
- Quick Order Code: 639648
- Barcode: 5055788268130
- Category: Downlights
- Range Name: Evofire
- Product Type: Fire Rated
- Product Body Finish: Antique Brass
- Market Segment: Commercial indoor, Residential indoor
- Finish: Antique Brass
- Features: With Insulation Guard
- Fixed/Tiltable: Fixed
- Warranty (Years): 3
Physical Data
Physical Data
- Product Depth (mm): 83
- Product Weight (g): 491
- Diameter (mm): 85
- Material: Steel, Glass
- Overall diameter (mm): 85
- Construction: Pressed Steel, Glass
- Cut Out Diameter (mm): 70
- Bulb or Luminaire Shape: Round
- Luminaire Fixing: Recess mounted
- Placement / Application: Indoor, General Lighting
Light Data
Light Data
- Fire Rating (mins): 30, 60, 90
Electrical Data
Electrical Data
- Insulation Guard: Yes
Environmental
Environmental
- CE RoHS: Yes
- IP Rating (Back/Recessed side): IP20
- IP Rating (Ingress Protection): IP65
