Integral LED

SLIM ECO IP20 BATTEN 3 CCT 5500LM 50W 3000/4000/6500K 120 BEAM 110LM/W 1500MM 5FT NON-DIMM INTEGRAL - ILBTE004

SLIM ECO IP20 BATTEN 3 CCT 5500LM 50W 3000/4000/6500K 120 BEAM 110LM/W 1500MM 5FT NON-DIMM INTEGRAL - ILBTE004

£16.56 exc. VAT
exc. VAT
exc. VAT
 £16.56

£19.87 inc. VAT
Sale Sold out
Shipping calculated at checkout.

The Integral LED Slim Eco Batten offers an affordable, easy to install and compact luminaire ideal for retrofits and installations in commercial, residential and other generalised applications.With onboard CCT switching functionality offering 3 colour temperature options (3000K, 4000K, 6500K), sizes from 1ft to 6ft and a highly efficient output of 110lm/W, there is a Slim Eco batten to suit your next refurbishment project.

Product Feature 1:
5500lm
Product Feature 2:
CCT switchable
Product Feature 3:
Easy installation
Product Feature 4:
3 Year warranty
  • Quick Order Code: 346008
  • Barcode: 5055788297352
  • Category: Luminaires
  • Range Name: Slim Eco
  • Type: Single
  • Product Type: Battens
  • Product Body Finish: Matt white
  • Market Segment: Indoor and Outdoor Commercial, Industrial, Residential
  • Finish: Matt White
  • Features: CCT Swtichable
  • Warranty (Years): 3
  • Emergency Option: No
  • Size (in ft): 5ft
  • Linkable: No
  • Product Length (mm): 1500
  • Product Depth (mm): 24.5
  • Product Width (mm): 75.5
  • Product Weight (g): 295
  • Optic: Polycarbonate diffuser
  • Material: Polycarbonate
  • Construction: PC extrusion
  • Bulb or Luminaire Shape: Linear
  • Luminaire Fixing: Wall/Ceiling mounted
  • Mounting Type: Side cable entry
  • Placement / Application: Indoor and outdoor, General lighting
  • Luminous Flux in Lumens (lm): 5500
  • Luminous efficacy (lm/W): 110
  • Correlated Colour Temperature (CCT) (K): 3000/4000/6500
  • Colour Temperature: 3000/4000/6500 - Warm White/Cool White/Cool Daylight
  • Colour Temperature Name: Warm White / Cool White / Cool Daylight
  • Beam Angle: 120
  • Colour Rendering Index (CRI): 80
  • Frequency Range (Hz): 50/60
  • Instant on (Less than 1 second): Yes
  • LED Size (mm): 2835
  • LED Type: Surface mounted device (SMD)
  • Lifetime (hours): 25000
  • Switching Cycles: 15000
  • Useful Lumens (lm): 5500
  • Power Consumption (W): 50
  • Power Factor: 0.9
  • Voltage Range (v): 220-240
  • Input Voltage (V): 220-240
  • Dimming: Non-Dimmable
  • Driver Included: Yes
  • Electric Current: AC
  • EN: EN-60598
  • LVD Certified: Yes
  • EN: EN-60598
  • LVD Certified: Yes
  • CE RoHS: Yes
  • EU Luminaire: L
  • Hg 0% (Mercury Free): Yes
  • IK Rating (Impact Protection): IK03
  • IP Rating (Ingress Protection): IP20
  • Lowest Operating Temperature (°C): -20
  • Maximum Operating Temperature (°C): 40
